Heze Boiler FactoryThe YY(Q)W type gas heat-conducting oil boiler produced by our company is a new type of special boiler with low pressure and high-temperature operating characteristics. Its heating temperature can reach up to 340℃ in the liquid phase or 400℃ in the vapor phase. It can serve as a high-temperature heat source for temperatures below 350℃, widely used in various industries that require high-temperature heating or drying. It features high temperature, low pressure, precise temperature control, and high thermal energy utilization. Optional steam generators can produce saturated steam below 1.3MPa for user use. Organic heat carriers can be used for heating in various production scenarios where uniform and stable heating is required and direct flame heating is not permitted, with heating temperatures ranging from 150℃ to 380℃.。This gas-fired organic heat carrier boiler typically uses oil or gas as fuel, with thermal oil as the medium. It employs a thermal oil circulating pump to force the medium into a liquid-phase circulation, transferring heat to the heating equipment and then returning it to the boiler for reheating. It offers high working temperatures at low pressure and allows for high-precision control of the medium's operation. The system has a high thermal utilization rate, is easy to operate and maintain, and is an ideal, safe, efficient, and energy-saving heating equipment of choice.。

Main Application:

Chemical Industry - Oil Chemicals, Polymer Industry, Reactor Vessels, Distillation, Concentration. Plastic Industry - Plastic Blowing, Extrusion Molding.

Textile Industry - Resin setting machines, dyeing machines, drying rooms, high-temperature machines, roller machines. Rubber Industry - Vulcanization heating of rubber.

Food Industry - Steaming, drying, and vegetable oil refining.林业工业 - Plywood, MDF, and fiberboard heating and shaping.

Paper Products Industry - Multi-layer cardboard for packaging boxes, drying, and dehydration. Other - Heating of metal electroplating tanks, curing of coatings, drying, pharmaceutical industry distillation, reduction, concentration, dehydration, etc.

Key Features:

The product's design, manufacturing, and inspection are strictly in accordance with the "Safety Supervision Code for Organic Heat Carrier Boilers," the "Safety Supervision Code for Hot Water Boilers," the GB/T17410-1998 "Organic Heat Carrier Boilers" standard, and regulations. It has also been inspected by the national special equipment safety supervision authority, ensuring safety and reliability.

2. The boiler heating surface is welded using argon gas protected full penetration welding, and has passed X-ray inspection and hydrostatic test with pressure retention, ensuring the welding quality exceeds national standards.

3. The diameter and length of the radiant coil are fully compatible with the flame of the matched burner to ensure reliable operation and adequate cooling of the coil.

4. The heating surface uses a higher yet reasonable flue gas velocity, based on precise calculations, to ensure adequate heat exchange in the furnace and maintain a high thermal efficiency of the boiler system.

The boiler body is constructed with a rational structural design and high-quality refractory and insulation materials, ensuring the external surface temperature of the boiler is ≤50°C, exceeding the national standards.

6. Boilers are assembled and shipped as whole units, allowing for the installation of the combustion, piping, and electrical control systems to begin immediately upon arrival at the customer's site. This features a notably shorter installation period and lower costs.

7. Utilizing imported burners from renowned international brands, ensuring reliable quality and trustworthiness.

Safety protection features and key control points:

Thermal oil export temperature display: Can be displayed on-site and remotely transmitted to the control cabinet for meter display. Users can set the temperature value, and it can be interlocked with the induced draft fan to achieve automatic adjustment of operation and high-temperature alarm.

2. Imported thermal oil temperature display: Can be locally displayed and remotely transmitted to the control cabinet for instrument display.

3. Thermal oil export pressure display: Can be locally displayed and remotely transmitted to the control cabinet for instrument display, with overpressure alarm function.

4. Thermal oil import pressure display: Can be locally displayed and remotely transmitted to the control cabinet for instrument display.

5. Expansion Tank Liquid Level Control: Enables low liquid level alarms in the expansion tank, promptly reminding the boiler operator to inject oil into the system, ensuring the safe and reliable operation of the boiler system.

Features of WNS series steam boilers:

Reasonably Designed: Horizontal internal combustion triple-return full-wet back design with 100% corrugated furnace tube, excellent thermal expansion properties. The water包围fire overall design with ample heating surface area and reasonable structural arrangement ensures high-efficiency operation of the boiler. Manufacturing Standards: The company has established a comprehensive quality assurance system that operates reliably, with the manufacturing process fully controlled and supervised by a special inspection office. High Efficiency and Energy Saving: Steam and hot water boiler series have a thermal efficiency of 87%-92%, with a large combustion chamber and reasonable structural arrangement to transfer more heat to the water, greatly enhancing the heat exchange capacity between fuel-steam and fuel-hot water. Environmental Compliance: Large combustion space, full utilization of radiant heat exchange, and high-quality imported burners ensure complete combustion of fuel, significantly reducing harmful emissions in flue gas. Legally tested, our fuel (gas) steam and hot water boilers meet national environmental protection standards and are ideal eco-friendly products. High Heating Quality: Steam boilers have ample steam storage space, ensuring high-quality dry steam is maintained even under large load fluctuations. Excellent Configuration: Equipped with world-renowned burners, advanced control systems (main components are imported), valves, and pumps all use national quality products. The excellent boiler accessories configuration provides a strong guarantee for the safe operation of the boiler. Fully Automatic Operation: The user only needs to press the start button, and the boiler will operate according to the set program. Load regulation, water supply, and other operations are fully automatic, requiring no专人 supervision. Long Service Life: Professional design, advanced production technology, and high-quality boiler-specific steel ensure that the boiler body has a lifespan of more than 15 years. Easy Maintenance: The boiler is equipped with removable smoke box doors at the front and rear, with observation and inspection holes at the rear for easy access to the combustion chamber for cleaning. The manhole on the boiler body is designed with future maintenance in mind.

WNS Fuel (Gas) Series Steam Boiler Application Fields:

1. Manufacturing and drying of chemical products, industrial chemicals, and pharmaceuticals for the chemical and pharmaceutical industries.

2. Industrial baking paints for automotive, motorcycle, container, household appliances, and metal can printing industries, as well as powder coating curing processes.

3. Heat setting, heat melting dyeing, baking, and hot air sizing for the textile printing and dyeing and non-woven industries.

4. Casting industry mold sand and sand core drying.

5. Sandpaper and grinding wheel drying for tool and abrasive industries.

6. Wood Drying for Construction Materials, Plywood Drying, Laminated Panel Drying, Gypsum Board Drying, Glass Fiber Products Drying.

7. Agricultural products, feed, and food processing: dried roasted coffee, tea, tobacco leaves, vegetables, grains, noodles, seafood, fish meal, soybean meal, etc.

8. Heating projects, industrial and residential building heating.

9. Welding materials: Welding rods and fluxes should be dried.

Insulating materials, silica-alumina fiber products for the glass fiber reinforced plastic industry, rare earth insulation, and drying of glass fiber reinforced plastic products.
