Product Details
Manufacturing and Sales: CNC machine tools and machine parts, mechanical equi...
产品Price 32000.00/Tai
最小起订Quantity：1 Tai 供货总Quantity： 9999 Tai
Swivel diameter on bed: 400 mm Swivel diameter on knife holder: 200mm Length between two topmost parts: 1000mm Bore diameter of main shaft: 52 mm Main shaft speed range (variable) 50-2200 rpm Spindle End Model ISO (GB) A2-6 Spindle Front Cone Hole, Morse 5 Main shaft motor power: 5.5 kW Main shaft motor type: Variable Frequency CNC Tool Holder, Vertical 4-Station Tool Holder Handle Size: 20×20mm Repeatability accuracy of knife holder ±3.2" X-axis travel 220mm Z-axis travel: 1000mm Fast Travel Speed X: 6000 mm/min Z: 8000 mm/min Feeding Speed Range X: 1~2000 mm/min Z: 1~2000 mm/min Set Unit 0.001 mm Tailstock sleeve diameter: 60 mm Tailstock sleeve stroke: 140 mm Tailstock sleeve tapered hole taper Morse 4 size Cooling Motor Power: 125W Flow Pump Head 5m Cooling pump flow rate: 25 L/min Power supply: 380V ±10%, 50Hz ±1%, three-phase AC Machine Tool Dimensions (Length × Width × Height): 2400mm × 1380mm × 1640mm Machine Tool Net Weight: 1600 kg
