Product Details
Manufacturing and Sales: CNC machine tools and machine parts, mechanical equi...
产品Price 888.00/Tai
最小起订Quantity：1 Tai 供货总Quantity： 777 Tai
Item Unit Specification Bed frame rotation diameter: 1250 mm Part Length: 1500-10000 mm Board Turn Diameter: 860mm Spindle End Type & Code: c11 Bore diameter: 105 mm Through bar diameter mm 100 Spindle Speed Range: 30-84; 300-835; 53-150; 125-350 Main Motor Power: 15 kW Collet, Four-jaw Collet, mm 630 X-axis rapid traverse speed m/min 4 Z-axis rapid traverse speed m/min 8 X-axis stroke mm 420 Z-axis travel mm 1350 Tailstock Sleeve Diameter/Stroke mm 100/250 Tailstock spindle taper - Morse taper 6# Standard Knife Holder Form - Vertical Four Tool Blade Size: Outer Diameter Knife mm 32×32 Tapered Tooling Rod Diameter mm φ32
