Product Details
Manufacturing and Sales: CNC machine tools and machine parts, mechanical equi...
产品Price 10500.00/Tai
最小起订Quantity：1 Tai 供货总Quantity： 57 Tai
An air hammer is a type of free forging equipment. The air compressor compresses air, which is then sent into the working cylinder through an allocation valve, driving the piston and hammerhead to move up and down, thus performing the striking action. Operation is flexible, and this model is suitable for various free forging processes such as extension, upsetting, piercing, shearing, welding, twisting, and bending. Various open-die forging operations can be carried out with the use of die blocks. Driven by compressed air, it meets the production needs with adjustable impact force and striking frequency controlled by air pressure regulation. 2. Cast iron for machine body, cast steel for large tonnage air hammer anvil. 3. Simple structure, not easily damaged Key Technical Parameters Unit C41-25Kg Drop Weight: 25 kg Impact Energy Kj 0.27 Strike Count min -1 250 Operating Height mm 215 Hammer shaft to hammer head distance: 200 mm Hammer Head Mold Size: mm 100x50x85 Forging Material Diameter, Round Steel mm Ø45 Square steel mm 40x40 Motor Parameters - Operating Voltage: V 220V, 380V Standard Power kW 3 Motor Speed: 1440 r.p.m. Dimensions: 900 mmx510x1200 Total Weight: 760 Kg
