Ozone GeneratorAlso known as a heavy-duty ozone generator.Shandong Huaxin Ozone Generator ManufacturerDrawing on ozone generation technology借鉴的臭氧制造技术，with years of extensive R&D and manufacturing expertise，凭借多年丰富的研发制造技术，Large Ozone GeneratorWe have a profound expertise in the manufacturing field. The following content is divided into five parts for a brief overview.Large Ozone GeneratorThe working principle content is available for reference.
Our large-scale ozone generator system consists of a gas source treatment system, an ozone discharge chamber, a cooling water system, a special ozone medium-frequency high-voltage power supply, and a control system.
Ozone Discharge Chamber
This section is for installing the ozone generator unit. The ozone generator unit is the basic component that forms the ozone production system, including electrodes and medium tubes.
(2) Electrode
It is the conductive portion that forms a conductive junction with media of different electrical conductivities; in the ozone generation unit, it refers to the conductive portion where a high-voltage electric field is distributed.
Body.
Medium Tube
Medium tube refers to the components made of materials that polarize under the action of the electric field, exhibiting basic electromagnetic field properties. In the ozone generation unit, it specifically denotes the insulator located between the two electrodes, responsible for creating a stable glow discharge.
(4) Power Supply
Power section includes a frequency-adjustable inverter controller for varying frequencies during discharge and a voltage booster that generates the required high voltage during discharge.TransformerComposed of wait.
(5) Large ozone generators produced by Shandong Hualin Ozone Generator Manufacturer use water cooling, effectively removing heat released during corona discharge with sufficient cooling water meeting quality requirements. The cooling water can be recycled and externally cooled. The generator's output can be adjusted according to the user's actual needs and is equipped with multiple protection functions to prevent damage in case of accidents.
