Lightweight
Company-developedBASModified cement perlite composite core material, bulk density less than600kg/m3The entire board weighs only about one-third of traditional concrete materials.30%。
·High-strength
Utilizing lightweight steel frame and high-strengthBASThe composite structure of inorganic lightweight core materials, while being a lightweight panel, retains the characteristics of high bearing capacity and safety of traditional reinforced concrete heavy panels. It can meet the requirements for uniformly distributed loads and also has strong central bearing capacity, making it an ideal material to replace traditional concrete roof and floor panels.
·Durable
The careful combination of material selection and construction methods ensures the product design has a long service life.50Year:
Core board is made of inorganic material, with good stability, resistance to aging, and a service life equivalent to concrete materials.
Wire diameter of the board bottom3mmAbove, protective layer thickness20mmMoreover, the moisture absorption rate is lower than0.1%；
Lumber has strong resistance to corrosion from acids, alkalis, and other gases.25After one freeze-thaw cycle, there is almost no change in volume and strength.
·Thermal Insulation
The boards feature excellent thermal insulation properties with a low thermal conductivity coefficient, and the overall heat transfer coefficient of the full board can be as low as0.3w/m2k Meets the thermal insulation and energy-saving requirements for construction in cold regions.
The boards feature excellent thermal insulation properties; the outer surface of the board heats up to900℃At that time, the inner temperature of the board was only50℃Ideal insulation material for high-temperature areas.
·Fire-resistant
Core boards are made of inorganic materials, are non-combustible, and do not crack or release toxic gases when exposed to fire, making them excellent refractory materials; the fire resistance limit of the whole board is greater than2Hours, meeting the first-level fire-resistant requirements for the components.
·Waterproof
Steel frame lightweight panels come with a dedicatedBASComposite waterproofing coating, when combined with the overall waterproofing method for roofs, forms a reliable composite waterproofing system, addressing the issue of leakage commonly found in lightweight panels.
·Relief Valve
Meets the requirements for special building roof and wall explosion venting and fragile performance. Laboratory tests show that during an explosion, the steel frame of the lightweight steel plate will remain in the main structure of the building, while the core material is instantly shattered, achieving the venting objective without causing secondary injury.
·Soundproof
Average sound insulation rating of panels40dbAbove, meets the soundproofing requirements for high-level acoustic buildings such as studios.
·Seismic-resistant
Steel frame light panels are lightweight materials that are beneficial for seismic resistance. With reasonable seismic joint design, they can meet8Seismic fortification intensity requirements for grades of earthquakes. Additionally, during an earthquake, the secondary damage caused by the boards is minimal, making them an ideal component material for buildings in seismic zones.
·Energy-saving and environmentally friendly
The main material of the board is all natural inorganic material, which does not release toxic or harmful substances, and the board has excellent breathability, ensuring healthy and comfortable living conditions.
The board production process utilizes part of industrial waste, classifying it as a product of comprehensive resource utilization.
·Convenient to use
Fast board installation, minimal construction stages, significantly shortening the construction period.
The panel shape and specifications can be customized according to customer requirements, meeting the needs for hole cutting and hanging objects, etc.
Panels provide a convenient and reasonable solution for the installation of skylights for natural lighting, ventilation equipment, lightning protection systems, and renovation work.
·Simple maintenance
Boards are easy to use with no special maintenance required, and have low operating costs; local damage can be repaired on-site directly, and individual boards can be replaced if necessary, without affecting the overall structure.
