Primary Application

Granulation and Coating of Pharmaceuticals. Granulation: tablet granules, syrup granules, granules for capsules. Coating: granule and pill coating, sustained-release, film, enteric coating. Granulation and Coating of Food. Caramel, coffee, cocoa powder, cream powder, fruit juice, amino acids, seasonings, puffed snacks. Agricultural pesticides, pigment dyes, dye granulation. Material drying in powder, granule, and block form.

Working Principle

Powdered material is introduced into an enclosed container through a hopper. Due to the action of hot gas flow, the powder suspends and circulates in a fluidized state, achieving uniform mixing. At the same time, a misty binder is sprayed to moisten the powder inside the container, causing it to agglomerate into loose, small particles. As the particles form, the hot gas flow dries them, causing moisture to evaporate and the powder to solidify continuously. This process is repeated, forming ideal, uniform, multi-porous spherical particles. The mixing, granulation, and drying processes are all completed in a single operation within the container.

Features:

1. Granulate powders, enhance flowability, and reduce dust飞扬.

2. Improve solubility through powder granulation.

3. Mixed - Granulated - Dried - All in One Machine (One-Step Granulation Process)

4. Utilizes anti-static filter material, with complete equipment operation.

5. Set pressure relief holes to ensure that personnel are not injured in the event of an explosion.

6. Equipment has no blind spots, making loading and unloading easy and fast, with thorough cleaning to meet GMP standards.
