35kV Oil-Immersed Power Transformer

Product Overview

Our 35kV (Loaded) power transformer is a new product independently developed and manufactured based on the absorption of advanced domestic and international technologies, specifically for the rural and urban power grid transformation in our country.Product performance exceeds GB/6451-2008 "Technical Parameters and Requirements for Oil-Immersed Power Transformers," fully conforms to GB1094 "Power Transformers" standard and International Electrotechnical Commission (IEC) standards.We recommend the standard IEC 60076 for this product, which boasts low loss, low noise, and no need for hanging concerns. It significantly improves in safety, reliability, and economy.The series power transformers are suitable for 35kV, 50Hz transmission and transformation systems. They are used as main transformers in urban grid renovation, industrial and mining enterprises, as well as 35kV transformer substations, and can operate under loaded conditions.In this case, remote voltage regulation for transformers is achieved. The product's technical performance indicators reach a relatively high level domestically.
