ZG-200YRD Two-Roll Open Mill, 8-inch Single-Speed Oil-Heated Open Mill (with Guardrail)

Mixed Capacity: 0.2—5 kgs

2. Roller Temperature: Room Temperature to 300℃

3. Heating Method: Oil Heating (Process Design, New Oil Heating Product, Automatic Temperature Control)

4. Temperature Accuracy: ±2℃ (High-precision PID intelligent microcomputer control system for the thermostat, with automatic calculation of internal constants, offering higher accuracy than manual settings, and saves time. Equipped with over-temperature protection to safeguard the machinery and production materials)

5. Roller Speed: Single Variable Speed / Single Speed (with 5.5 kW variable frequency drive unit)

6. Roller Speed Ratio: 1:1.27 ratio available for customization as per customer requirements.

7. Roller Size: φ200mm × L500mm (high hardness surface hard chrome plating treatment, non-stick, non-peeling)

8. Roller Spacing: adjustable from 0.1 to 8mm

9. Safety Device: Multiple push-button emergency stop switches (with reverse function, ergonomic design, ensuring no worker injuries)

10. Motor: 5.5KW, 1 unit

11. Power: 15 kW

12. Volume: (W×D×H) 1900×850×1380mm; smaller than traditional manufacturing methods with the same functionality. 13. Roller Lubrication: The highly wear-resistant bearings have a larger contact area, extending the service life by two-thirds compared to traditional copper bushes.

14. Mechanical Structure: Steel plate (lighter, smaller in volume than cast iron used in traditional processes, with higher mechanical strength and better toughness)

15. Power: 5 poles, AC 380V

16. Weight: Approximately 1000 kg
