Name:Integrated Clamp-on Ultrasonic Flow Meter
Model:F6
Dimensions:139*71*95mm
Brief Description:
Small-bore External Flanged Ultrasonic Flow Meters, available in DN15-DN40 small bore sizes. Easy installation and operation. No need to break pipes or shut down for long periods; installation can be completed in just a few minutes with ease.
The F6 features a brand-new external flange design, eliminating the need to contact the measuring medium. It can avoid pressure loss and medium contamination caused by traditional flowmeters. Multiple modes are available for setup, offering flexibility and variety. One machine is universally applicable for measuring all diameters within its range and is suitable for various metal and resin pipes.
Optional for ultrasonic cold (hot) gauge, to achieve energy consumption monitoring and measurement.
Key Features:
1. 256*128 large screen LCD with backlit display
2. Acrylic logo labels, convenient for OEM branding.
3. Adjustable sensor distance, universal for DN15-DN40.
4. M12 aviation connector, no wiring required.
Standard with 4-20mA and RS485 interface.
Pipe Diameter Parameters:
| Pipe diameter | Maximum Flow Rate (L/min) |
| 15 | 60 |
| 20 | 100 |
| 25 | 200 |
| 32 | 300 |
| 40 | 400 |
Note: Inner diameter of measurable pipe section is 12mm or greater.
