Product Introduction
The KeDaJinWei glass laser drilling machine uses high-energy, high-precision lasers to cut and drill glass materials. With high-definition image alignment and a professional, customizable operation software control system, production efficiency is increased, repeat positioning is more accurate, and operation is simpler. This equipment is currently widely used in industries such as instrument glass, photovoltaic glass, mobile phone glass, vehicle-mounted displays, and panel display glass.
Product Features
Laser non-contact processing, causing no hard damage to the product; water-cooling-free processing, environmentally friendly and pollution-free; no consumables required, supports7*24Operates hour-round with excellent long-term stability; fast processing speed, high efficiency, minimal burr, and low power consumption.
This equipment is primarily composed of marble frame sheet metal, motion gantry modules, and a vacuum吸附 platform.CCDThe assembly consists of mating mechanisms, panel placement fixtures, laser systems, manual unloading platforms, and electrical control systems.
Support customization
Equipment supports customization with optional single-head, dual-head, standalone, wired, and other non-standard functions.
| Machine tool cutting effective stroke | 500×2500 (mm) available |
| Processing positioning method | CCD Positioning Optional |
| Laser Wavelength | 532-1064nm Optional |
| Laser Power | 10-200k available |
| Repetitive Accuracy | 0.005mm |
| Positioning Accuracy | ±0.01mm |
| Processed burr-free | ≤ 70um |
| Minimum Drilling Hole Diameter | 0.1mm |
| Single-lens Cutting Area | 50mm - 150mm available |
| Glass thickness range | ≤ 0.5-19mm options |
| Electric Power Demand | AC220-380V available |
