Bed frame rotation diameter: Φ800 mm

Skid Turning Diameter: 430mm

Cutting Diameter: mm Φ800

Processing Length: mm 5850

Travel of X/Y Axis: mm 450/6000

X/Z Axis Displacement Unit mm 0.001

Bearing bore diameter: 105mm

Main shaft speed: 4-speed stepless variable speed

Main shaft maximum speed: 25-850 rpm

Main Motor Power (Variable Frequency) 11 kW

VFD 11 kW

X/Y Axis N.m 15/22

X/Z axis rapid traverse speed 4/6 m/min

4-Station Electric Knife Holder (Wenchang) Type

Tooling Size: 25mm x 25mm

Repeat positioning accuracy of knife holder: mm ≤ 0.004

Tailstock Sleeve Diameter mm Φ75

Tailstock sleeve stroke: 200 mm

Tailstock Tip Bore, M5#

Power Demand (Power/Current) kW/A 20kW/30A
