Item Unit Specification

Bed frame rotation diameter: 1250 mm

Part Length: 1500-10000 mm

Board Turn Diameter: 860mm

Spindle End Type & Code: c11

Bore diameter: 105 mm

Through bar diameter mm 100

Spindle Speed Range: 30-84; 300-835; 53-150; 125-350

Main Motor Power: 15 kW

Collet, Four-jaw Collet, mm 630

X-axis rapid traverse speed m/min 4

Z-axis rapid traverse speed m/min 8

X-axis stroke mm 420

Z-axis travel mm 1350

Tailstock Sleeve Diameter/Stroke mm 100/250

Tailstock spindle taper - Morse taper 6#

Standard Knife Holder Form - Vertical Four

Tool Blade Size: Outer Diameter Knife mm 32×32

Tapered Tooling Rod Diameter mm φ32
