Swivel diameter on bed: 1250mm

Swivel diameter on the blade holder: 860mm

Track Width: 755mm

Spindle End A2-11/15

Bore diameter of main shaft: 105 mm

Spindle Speed: 30-835 RPM

Spindle Manual Gearbox Four-Speed

Trolley Z-axis movement unit 0.001mm/min

Trolley X-axis movement unit 0.001mm/min

Trolley X-axis travel 1250mm

Trolley Z-axis travel 3000mm

Processing Length: 2850mm

Trolley rapid movement speed: 6000/4000 mm/min in X/Z direction

Tailstock sleeve conical bore, Morse 6 size

Tailstock sleeve diameter: 150mm

Tailstock sleeve stroke: 250mm

Main Motor Power: 18.5 kW

Z-axis repeat positioning accuracy: 0.015mm

X-axis repeat positioning accuracy: 0.01mm

Repeating positioning accuracy of electric knife holder: 0.002mm

Overall Weight (Approx.) 10,000 Kg

Machine tool external dimensions: 5600x2200x2400mm
