The YX-A series high-temperature furnace, as shown, integrates the control system with the furnace chamber. The furnace lining is made of vacuum-formed high-purity alumina lightweight material.
Utilizing high-temperature electric heating elements for heating; this equipment is specifically designed for laboratories in colleges and research institutions, as well as industrial and mining enterprises, for sintering, melting, analysis, and production of ceramics, metallurgy, electronics, glass, chemicals, machinery, refractory materials, new materials development, special materials, construction materials, metals, non-metals, and other chemical substances.
The control panel is equipped with an intelligent temperature regulator, power switch, main heating start/stop button, voltage and current meters, computer interface, and observation/hatch for easy monitoring of the system's operating status. This product utilizes reliable integrated circuits, operates in a favorable environment, is resistant to interference, and maintains the outer shell temperature of the furnace ≤45℃ at high temperatures, significantly improving the working environment. It features microcomputer program control, programmable curves, automatic heating/cooling, and allows for the modification of temperature control parameters and programs during operation, offering flexibility, convenience, and simple operation.
